Claims-Based Security (CBS) Authentication

Experimental

CBS authentication support is an experimental feature.

The AMQP connector supports Claims-Based Security (CBS) for token-based authentication with AMQP 1.0 brokers. CBS allows the client to authenticate by sending a security token (such as a JWT or SAS token) to the broker over the AMQP connection, rather than relying solely on SASL mechanisms. This is commonly used with brokers like Azure Service Bus.

Enabling CBS

To enable CBS authentication on a channel, set the cbs.enabled attribute:

1
2
3
4
5
mp.messaging.incoming.my-channel.connector=smallrye-amqp
mp.messaging.incoming.my-channel.host=my-broker.servicebus.windows.net
mp.messaging.incoming.my-channel.port=5671
mp.messaging.incoming.my-channel.use-ssl=true
mp.messaging.incoming.my-channel.cbs.enabled=true

CBS can be enabled on both incoming and outgoing channels independently.

Providing Tokens

When CBS is enabled, the connector requires a CDI bean implementing CbsTokenProvider. This bean is called during initial connection and on each token refresh cycle.

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
@ApplicationScoped
public class MyCbsTokenProvider implements CbsTokenProvider {

    @Override
    public Uni<CbsToken> getToken(AmqpConnectorCommonConfiguration config) {
        String token = fetchTokenFromAuthService();
        return Uni.createFrom().item(new DefaultCbsToken(
                token,
                "jwt",
                OffsetDateTime.now().plusHours(1),
                OffsetDateTime.now().plusMinutes(45)));
    }

    private String fetchTokenFromAuthService() {
        // Retrieve a token from your identity provider
        return "my-jwt-token";
    }
}

The getToken method receives the channel configuration, allowing you to adapt token generation per channel (e.g., using different audiences or scopes). It returns a Uni<CbsToken> to support non-blocking token retrieval from external identity providers.

The CbsToken Interface

A CbsToken provides:

Method Description
token() The token string value (JWT, SAS token, etc.)
type() The token type (e.g., "jwt" or "servicebus.windows.net:sastoken")
expiresAt() When the token expires
refreshAt() When the token should be refreshed (defaults to expiresAt() if not set)

The DefaultCbsToken record provides a convenient implementation:

1
2
3
4
5
6
7
8
// With explicit refresh time (refresh before expiration)
new DefaultCbsToken(token, "jwt", expiresAt, refreshAt);

// Refresh at expiration
new DefaultCbsToken(token, "jwt", expiresAt);

// Using validity duration in seconds
new DefaultCbsToken(token, "jwt", 3600);

Token Refresh

The connector automatically refreshes tokens before they expire. After a successful authorization, a timer is scheduled based on the refreshAt() value of the token.

  • If refreshAt() is set earlier than expiresAt(), the token is refreshed proactively.
  • If the refresh fails after retries, the connection is closed and re-established.

Setting refreshAt() earlier than expiresAt() is recommended to avoid authentication gaps during refresh:

1
2
3
4
new DefaultCbsToken(
    token, "jwt",
    OffsetDateTime.now().plusHours(1),      // expires in 1 hour
    OffsetDateTime.now().plusMinutes(45));   // refresh after 45 minutes

CBS Exchange Protocols

The connector supports two CBS exchange protocols, configured with cbs.exchange:

set-token (default)

The set-token protocol sends the token as an AMQP message to the CBS node with:

  • Subject: set-token
  • Application property token-type: the token type
  • Body: the token string

The broker acknowledges the message to confirm the token was accepted.

1
mp.messaging.incoming.my-channel.cbs.exchange=set-token

put-token

The put-token protocol uses a request-reply exchange, compatible with Azure Service Bus. It sends the token as a request and validates the response status code.

1
2
mp.messaging.incoming.my-channel.cbs.exchange=put-token
mp.messaging.incoming.my-channel.cbs.audience=my-namespace.servicebus.windows.net/my-queue

When using put-token, the cbs.audience attribute sets the token audience. If not configured, the audience is derived from the broker host and target address in the format amqp://HOST/ADDRESS.

Connection Sharing with CBS

When multiple channels share the same connection using container-id, CBS authentication is performed once for the shared connection:

1
2
3
4
5
6
7
mp.messaging.incoming.my-channel-in.connector=smallrye-amqp
mp.messaging.incoming.my-channel-in.container-id=shared
mp.messaging.incoming.my-channel-in.cbs.enabled=true

mp.messaging.outgoing.my-channel-out.connector=smallrye-amqp
mp.messaging.outgoing.my-channel-out.container-id=shared
mp.messaging.outgoing.my-channel-out.cbs.enabled=true

Both channels share a single connection and a single CBS token authorization.

Azure Service Bus Example

To connect to Azure Service Bus using CBS with SAS tokens:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
@ApplicationScoped
public class MySasTokenProvider implements CbsTokenProvider {

    @Override
    public Uni<CbsToken> getToken(AmqpConnectorCommonConfiguration config) {
        String sasToken = generateSasToken(config.getHost());
        return Uni.createFrom().item(new DefaultCbsToken(
                sasToken,
                "servicebus.windows.net:sastoken",
                3600)); // valid for 1 hour
    }

    private String generateSasToken(String host) {
        // Build a SAS token for Azure Service Bus
        return "SharedAccessSignature sr=...";
    }
}

1
2
3
4
5
6
7
mp.messaging.incoming.my-channel.connector=smallrye-amqp
mp.messaging.incoming.my-channel.host=my-namespace.servicebus.windows.net
mp.messaging.incoming.my-channel.port=5671
mp.messaging.incoming.my-channel.use-ssl=true
mp.messaging.incoming.my-channel.cbs.enabled=true
mp.messaging.incoming.my-channel.cbs.exchange=put-token
mp.messaging.incoming.my-channel.cbs.audience=my-namespace.servicebus.windows.net/my-queue

Retry Configuration

If token authorization fails, the connector retries with exponential backoff. The retry behavior is controlled by the standard connector retry attributes:

1
2
mp.messaging.incoming.my-channel.retry-on-fail-attempts=6    # max retries (default: 6)
mp.messaging.incoming.my-channel.retry-on-fail-interval=5    # retry delay in seconds (default: 5)

If all retries are exhausted, the connection is closed and re-established using the connector's reconnection mechanism.

Configuration Reference

Attribute Type Default Description
cbs.enabled boolean false Enable CBS authorization
cbs.exchange string set-token CBS exchange protocol: set-token or put-token
cbs.audience string Token audience (auto-derived from address if not set)
cbs.scopes string Token scopes for authorization
cbs.token-manager string default-cbs-token-manager CDI bean identifier of a custom CbsTokenManager.Factory

All attributes are available for both incoming and outgoing channels.
